Description
产品文字介绍产品文字介绍产品文字介绍产品文字介绍产品文字介绍产品文字介绍产品文字介绍产品文字介绍产品文字介绍产品文字介绍
Available models:
- DS-2CD6924G0-IHS/NFC(2.8mm)
- DS-2CD6924G0-IHS/NFC(6mm)
- DS-2CD6924G0-IHS(2.8mm)
- DS-2CD6924G0-IHS(6mm)
Specification
WIRELESS
DIMENSION AND WEIGHT
CAMERA
VIDEO & AUDIO
SCREEN
BATTERY
INTERFACE
ENVIRONMENTAL
WIRELESS
WIRELESS
| Wi-Fi | 802.11b/g/n 2.4GHz(AP mode) |
| GPS | Glonass/GPS combined positiong |
DIMENSION AND WEIGHT
DIMENSION & WEIGHT
| Dimension | 84 x 61 x 28.5 mm (3.31 x 2.4 x 1.12 in) |
| Weight | 159 g (5.6 oz) |
CAMERA
CAMERA
| Image Sensor | 1/3 CMOS″ |
| FOV | Horizontal angle 120° Diagonal angle 150° |
| Aperture | F2.0 |
| Image Format | JEPG |
| Image Resolution | 42MP |
VIDEO & AUDIO
VIDEO & AUDIO
| Video format | MP4 |
| Video Resolution | 2304x1296@30fps , 1920x1080@30fps , 1280x720@30fps, 848X480@30fps |
| Video compression | H.264 |
| Pre-record | 19S |
| Post-record | 10mins |
| IR | 15M |
| Day / Night Operation | 0.1 lux |
| Water mark | Support |
| MIC Audio format | Dual Micphone (silicon microphone) with noise reduction AAC |
| Speaker | 1.5W Waterproof speaker |
| Recording Storage Capacity | Default 32GB, 64/128/256/512 GB optional |
SCREEN
SCREEN
| Resolution | 96 x 32 |
| Screen Size | Dot-matrix display |
| Touchscreen | N/A |
BATTERY
BATTERY
| Battery type | Lithium battery(Built-in battery) |
| Battery capacity | 4200mAh |
| Charging time | Less than 4H |
| Recording time | 16 hrs |
INTERFACE
INTERFACE
| Button | Power,Video recording,Voice recording,Snapshot,Fu,IR |
| Charging Interface | Type-C |
| USB | USB 2.0 |
| Docking | With charging dock |
ENVIRONMENTAL
ENVIRONMENTAL
| Water proof | IP66 |
| Drop test | 2M |
| Working Temperature | -30～55℃ |
| Working humidity | 40%～80% |
